HEAT TORCH INLINE AIR HEATERS
Tutco-Farnam has been manufacturing high-quality inline heaters for over two decades. Tens of thousands of these devices have been built for many Fortune 1000 companies on a custom order basis. Based on this experience and increased demand, we created a family of Heat Torch™ process heaters which can be modularly assembled from a set of components to provide the best of both standardization and flexibility.
Farnam Heat Torch™ inline air heaters are ideal for rapidly heating compressed air or any non-combustible gas. Industrial strength open coil heating elements provide efficient heat transfer through direct contact with high-pressure airflow. Rapid heater response time enables precise output temperature control when these heaters are paired with off the shelf sensors and controllers. Robust design, high-quality materials, and workmanship provide long life and performance margin. We provide pressure testing for any of our Heat Torch™ products as an add-on service
PRODUCT |
MAX WATT |
MAX INLET |
MAX EXHAUST |
MIN SCFM |
MAX SCFM |
PSIG* |
|
|
300W | 250°F | 932°F | 0.3 | 1 | 120 |
Heat Torch™ 030 LEARN MORE
PRODUCT |
MAX WATT |
MAX INLET |
MAX EXHAUST |
MIN SCFM |
MAX SCFM |
PSIG* |
|
|
600W | 250°F | 1300°F | 1 | 10 | 120 |
 |
600W | 250°F | 932°F | 1 | 10 | 120 |
Heat Torch™ 050 LEARN MORE
PRODUCT |
MAX WATT |
MAX INLET |
MAX EXHAUST |
MIN SCFM |
MAX SCFM |
PSIG* |
 |
1000W | 250°F | 1300°F | 1.3 | 25 | 120 |
|
|
1000W | 250°F | 932°F | 1.3 | 25 | 120 |
Heat Torch™ 075 LEARN MORE
PRODUCT |
MAX WATT |
MAX INLET |
MAX EXHAUST |
MIN SCFM |
MAX SCFM |
PSIG* |
|
|
5000W | 250°F | 1300°F | 4.8 | 70 | 120 |
Heat Torch™ 150 LEARN MORE
PRODUCT |
MAX WATT |
MAX INLET |
MAX EXHAUST |
MIN SCFM |
MAX SCFM |
PSIG* |
|
|
12500W | 250°F | 1300°F | 9.6 | 100 | 120 |
